Telit ME910C1-WW Mini PCIe LTE-M and NB-IoT module, top-down view of the Cat M1 / NB1 LPWA card

Telit ME910C1-WW Mini PCIe LTE-M & NB-IoT Module

SKU: S135 In stock

Ships from Germany in 1–3 business days
2-year warranty
Secure checkout

Description

The Telit ME910C1-WW is the core engine for building cellular IoT solutions, particularly for Raspberry Pi applications when paired with complementary hardware like the Base HAT and an LTE antenna.

Worldwide coverage with LTE UE Category M1/NB1, 3GPP release 13 compliant, with 2G fallback.

Performance at a glance

LTE-M + NB-IoTCat M1 / NB1, 2G fallback
300 / 375 kbpsCat M1 DL / UL
−40 → +85 °COperating temperature

Highlights

Worldwide coverageLTE UE Category M1/NB1, 3GPP release 13 compliant, with 2G fallback.
Power saving3GPP Rel. 12 Power Saving Mode (PSM) and extended discontinuous reception.
ConnectivitySMS and internet connectivity via integrated TCP/IP and UDP/IP stacks.
PositioningGPS and GNSS support.
FirmwareFirmware Over-the-Air (FOTA) updates; battery-friendly 1.8 V GPIO.

Technical specifications

Frequency bands
Best for	IoT applications with ultra-compact design and extended temperature requirements
Regions	Global or Regional
Max. data speeds	LTE Cat M1: 300 kbps (DL) / 375 kbps (UL) · LTE Cat NB1: 21 kbps (DL) / 62.5 kbps (UL)
Positioning	GPS, GNSS
Electrical	Nominal: 3.3 VDC · Range: 3.0-3.6 VDC
Operating temp	-40 °C to +85 °C
Dimensions	51 x 30 x 3.2 mm
Interfaces	USB 2.0 HS, UART, GPIO
Antenna	Single Rx, single LTE antenna
Approvals	PTCRB, GCF, RED, FCC/IC, RCM, Jate, Telec, CCC, AT&T, Verizon, NTT DoCoMo, Deutsche Telekom, Anatel, Telstra, Ifetel, Rogers, Telus, US Cellular
Compliance	RoHS, REACH
4G bands (MHz)	B1 (2100), B2 (1900), B3 (1800), B4 (AWS 1700), B5 (850), B8 (900), B12 (700), B13 (700), B18 (800), B19 (800), B20 (800), B26 (850), B28 (700)
2G bands (MHz)	B2 (1900), B3 (1800), B5 (850), B8 (900)
